TWO PERSON LIFTING OPERATION

ONE PERSON LIFTING OPERATION

Keep your operator safe

Operator safety starts with the right equipment. We offer a range of standard manipulators for common applications, as well as custom-engineered solutions tailored to your unique process. No matter your setup, we’ll help you lift and move parts safely and efficiently.

VIEW CUSTOM SOLUTIONS

REQUEST A QUOTE

  • This field is for validation purposes and should be left unchanged.

Standard Models:

PM-22-S PM-22-A
PM-23-S PM-23-A
PM-24-S

Reach: 16”-64” | 4”-76” | 8”-88”

Vertical Stroke: 23”

Lift Capacity: 0-200 lbs | 0-150 lbs

Air: 90 PSI

PM-32-S PM-32-A
PM-33-S PM-33-A
PM-34-S

Reach:  28”-76” | 16”-89” | 4”-101”

Vertical Stroke: 38”

Lift Capacity: 0-150 lbs

Air: 90 PSI

PM-42-S PM-42-A
PM-43-S PM-43-A
PM-44-S

Reach: 40”-88” | 28”-101” | 16”-113”

Vertical Stroke: 52”

Lift Capacity: 0-90 lbs

Air: 90 PSI

NEED A CUSTOM LIFTING SOLUTION

TELL US YOUR CHALLENGE

CUSTOM SOLUTIONS:

TELL US YOUR LIFTING CHALLENGE

TELL US YOUR LIFTING CHALLENGE

  • This field is for validation purposes and should be left unchanged.

  • This form must be used when requesting a quotation for a custom engineered FlexArm Part Manipulator End Effector to ensure the specifics of the application are understood from the start and is successful throughout the design, approval, manufacture, and implementation process.
